KAA10XL0 customized thin section ceramic ball bearing

KAA10XL0 customized thin section ceramic ball bearing

KAA10XL0 customized thin section ceramic ball bearing
  • KAA10XL0 customized thin section ceramic ball bearing
  • KAA10XL0 customized thin section ceramic ball bearing
  • KAA10XL0 customized thin section ceramic ball bearing
  • Bearing:KAA10XL0
  • d:1
  • D:1.375
  • B:0.1875
  • L1:1.14
  • L2:1.235
  • Weight:0.026
  • Balls:ceramic ball
  • Application:Robtos.UAV platform
  • Price:Ask
  • Delivery:Stock
Inquiry Now

KAA10XL0 customized thin section ceramic ball bearing

customized thin section ball bearings


Bearing
    Number
Dimensions in InchesCapacitieslbsWightlbs
BoreOutside
    Dia.
L1L2RadialaxialTorquein-lbs
DynamicStaticDynamicStaticDynamicStatic
KAA10XL01.0001.3751.1401.2352902477303701701100.026

MONTON thin section ball bearings are engineered to solve avariety of design problems that cannot be solved withconventional ball bearings.A bearing is considered a thin section when the bore diameter is greater than four times the radial cross section.Within any thin section ball bearing series, the cross section

remains constant as the bore diameter changes. Typically the cross section is twice the ball diameter, and nominaldimensions are given in inches.

MONTON thin section ball bearings are most often found where space limitations, combined loading, and weight restrictions pose unique design requirements.


MONTON also designs and manufactures special thin sectionball bearings tailored for specific applications.
