234418M.SP Double Direction Angular Contact Thrust Ball Bearing ,Special Precision, Brass Cage, 90 mm ID, 140 mm OD, 140 mm Width 60mm
Home / MONTON Bearing / Sales Center / 234418M.SP Double Direction Angular Contact Thrust Ball Bearing ,Special Precision, Brass Cage, 90 mm ID, 140 mm OD, 140 mm Width 60mm
234418M.SP Double Direction Angular Contact Thrust Ball Bearing ,Special Precision, Brass Cage, 90 mm ID, 140 mm OD, 140 mm Width 60mm
234418M.SP Double Direction Angular Contact Thrust Ball Bearing ,Special Precision, Brass Cage, 90 mm ID, 140 mm OD, 140 mm Width 60mm
- Bearing:234418M.SP
- d:90mm
- D:140mm
- T:60mm
- Weight:2.92KG
- Contact angle:60 °
- Brand:Monton
- Application:machine tool
- Packing:single box
- Origin:Luoyang
- Price:ask
- Delivery:stock
| Bearings | Demension | Assembly Demension | Loading | RPM | Oil groove and oil hole | stiffness | Weight | |||||||||||||
| d | D | d1 | T | C | B | rsmin | r1smin | da | Da | ra | rb | Ca | Coa | Lub | Oil | n | k | Ra | ≈ | |
| mm | min | max | max | max | kN | r/min | mm | N/μm | Kg | |||||||||||
| 234418M | 90 | 140 | 123 | 60 | 30 | 15 | 1.5 | 0.3 | 110.5 | 130.5 | 1.5 | 0.3 | 61 | 146 | 4000 | 5300 | 9.5 | 4.8 | 708 | 2.92 |
We supply high-quality 234418M.SP bearing.
FAG 234418M.SP bearing are widely used in motor, industrial machinery, CNC lathes, high-precision processing machine, locomotive industry.
