  • Bearing:YRT260P4
  • type:YRT Bearing
  • d:260mm
  • D:385mm
  • H:55mm
  • Speed:200 r/min
  • Weight:18.3KG
  • Application:CNC Rotary Table
  • Brand:MONTON
  • Origin:Luoyang
  • Delivery:7 days
  • Price:ask
  • Packing:Wooden Case
Inquiry Now

YRT260P4

bearing type Dimensions  fixing holesNumber of retaining   screws
dDHH1CD1JJ1inner   ringouter   ring
unit mmd1d2aqtyd3qty
mmmm
YRT2602603855536.5183452803659.3158.2349.3332


bearing type Extraction   thread holeNumber of pitches X   angle of pitches

Screw tightening torqueBasic   load ratingLimiting speed

Bearing frictional torqueweight
axialradial
dynamic loadstatic   loaddynamic   loadstatic   load
MA2)CaCoaCrCorgrease
Gqtyqty×t

NmKNr/minNmKg
YRT260M12336×10°341601060932902002018.3
                                                   Machining tolerances for shafts
Bearingsshaft diameter mmroundness(○)perpendicularity(⊥)parallelism(∥)roughness Ra
Nominal dimensionupperlowert1µmt3µmt4µmRaµm
YRT2602600-0.02312880.8
                                                     Machining tolerances for housings
Bearingsmmhousing   diameterroundness(○)perpendicularity(⊥)parallelism(∥)roughness Ra
Nominal dimensionupperlowert1µmt3µmt4µmRaµm
YRT260385+0.029-0.00713990.8


YRT260P4 YRT bearing

YRT260P4 YRT bearing

YRT260P4 YRT bearing

YRT260P4 YRT bearing

YRT series turntable bearing with a set of radial roller, two groups of thrust roller cage full components of composite structure design, an outer ring, a l-shaped inner ring and the inner ring, inner and outer ring with mounting holes, and before delivery or addition of pre-load, not only simplify the structure of the components, reduced the workload of installation, reducing the high requirements for installation.Therefore, for low-speed and short-time operation occasions with high precision, high rigidity and bearing joint load requirements, such as dividing table and rotary milling head, it is extremely suitable to choose YRT series rotary table bearing.
