Product Description

Stainless Steel type Four Contact thin section ball bearing

>>

<<

Select	Download	Inquiry	Bearing Number	Dimensions in Inches				Capacities（lbs）						Wight（lbs）
				Bore	Outside Dia.	L1	L2	Radial		axial		Torque（in-lbs）
				Bore	Outside Dia.	L1	L2	Dynamic	Static	Dynamic	Static	Dynamic	Static
			SAA10XL0	1.000	1.375	1.14	1.235	290	247	730	370	170	110	0.026
			SAA15XL0	1.500	1.875	1.64	1.735	400	296	1.000	460	340	187	0.039
			SAA17XL0	1.750	2.125	1.89	1.985	460	319	1.140	500	440	232	0.045
			SA020XP0	2.000	2.5	2.186	2.314	680	514	1.710	790	770	434	0.1
			SA025XP0	2.500	3	2.686	2.814	830	583	2.090	910	1.150	601	0.13
			SA030XP0	3.000	3.5	3.186	3.314	990	643	2.470	1.010	1.600	785	0.15
			SA035XP0	3.500	4	3.686	3.814	1.140	701	2.850	1.110	2.130	986	0.18
			SA040XP0	4.000	4.5	4.186	4.314	1.290	756	3.220	1.210	2.740	1.205	0.19
			SB020XP0	2.000	2.625	2.231	2.393	930	758	2.340	1.130	1.080	658	0.16
			SB025XP0	2.500	3.125	2.731	2.893	1.140	848	2.840	1.290	1.600	895	0.19
			SB030XP0	3.000	3.625	3.231	3.393	1.340	933	3.350	1.440	2.220	1.159	0.24
			SB035XP0	3.500	4.125	3.731	3.893	1.540	1.014	3.860	1.590	2.940	1.450	0.27
			SB040XP0	4.000	4.625	4.231	4.393	1.750	1.091	4.370	1.720	3.770	1.764	0.3

>>

<<
