618 Series Deep Groove Ball Bearing

Catalogue

Advanced Search

Printable Page Email

Email This Page

Save To Favorites

Product Description

Inquiry Now

>>

<<

Select	Model	Dimension			Basic load rating		Rated Speed		Dimension				The dimensions of the shoulder and chamfer				Computing coefficients		Weight	Brand
	-	-	-	-	Dynamic	static	Reference speed	limit speed1	d1	D1	D2	r1,2	da	da	Da	ra	-	-	-
	-	d	D	B	C	C0	r/min	r/min	≈	≈	≈	Min	Min	Max	Max	Max	kr	f0	-
	-	mm	mm	mm	kN	kN	-	-	mm	mm	mm	mm	mm	mm	mm	mm	-	-	kg
	618/4	4	9	2.5	0.423	0.116	140 000	85 000	5.2	7.5	–	0.1	4.6	–	8.4	0.1	0.015	6.5	0.0007	MONTON
	618/5	5	11	3	0.468	0.143	120 000	75 000	6.8	9.2	–	0.15	5.8	–	10.2	0.1	0.015	7.1	0.0012	MONTON
	618/6	6	13	3.5	0.715	0.224	110 000	67 000	8	11	–	0.15	6.8	–	12.2	0.1	0.015	7	0.002	MONTON
	618/7	7	14	3.5	0.78	0.26	100 000	63 000	9	12		0.15	7.8		13.2	0.1	0.015	7.2	0.0022	MONTON
	618/8	8	16	4	0.819	0.3	90 000	56 000	10.5	13.5	–	0.2	9.4	–	14.6	0.2	0.015	7.5	0.003	MONTON
	618/9	9	17	4	0.871	0.34	85 000	53 000	11.5	14.5	–	0.2	10.4	–	15.6	0.2	0.015	7.7	0.0034	MONTON
	61800-2RS1	10	19	5	1.72	0.83	–	22 000	–	–	17.2	0.3	11.8	11.8	17	0.3	0.015	15	0.0055	MONTON
	61800-2Z	10	19	5	1.72	0.83	80 000	38 000	12.7	–	17.2	0.3	12	12.5	17	0.3	0.015	15	0.0055	MONTON
	61800	10	19	5	1.72	0.83	80 000	48 000	12.7	16.3	–	0.3	12	–	17	0.3	0.015	15	0.0053	MONTON
	61801-2RS1	12	21	5	1.74	0.915	–	20000	–	–	19	0.3	13.6	13.8	19	0.3	0.015	13	0.0063	MONTON
	61801-2Z	12	21	5	1.74	0.915	70 000	36 000	14.8	–	19	0.3	14	14.7	19	0.3	0.015	13	0.0063	MONTON
	61801	12	21	5	1.74	0.915	70 000	43 000	14.8	18.3	–	0.3	14	–	19	0.3	0.015	13	0.0063	MONTON
	61802-2RS1	15	24	5	1.9	1.1	–	17 000	17.8	–	22.2	0.3	17	17.8	22	0.3	0.015	14	0.0074	MONTON
	61802-2Z	15	24	5	1.9	1.1	60 000	30 000	17.8	–	22.2	0.3	17	17.8	22	0.3	0.015	14	0.0074	MONTON
	61802	15	24	5	1.9	1.1	60 000	38 000	17.8	21.3	–	0.3	17	–	22	0.3	0.015	14	0.0065	MONTON
	61803-2RS1	17	26	5	2.03	1.27	–	16 000	19.8	–	24.2	0.3	18	18.6	24	0.3	0.015	14	0.0082	MONTON
	61803-2RZ	17	26	5	2.03	1.27	56 000	28 000	19.8	–	24.2	0.3	19	19.6	24	0.3	0.015	14	0.0082	MONTON
	61803-2Z	17	26	5	2.03	1.27	56 000	28 000	19.8	–	24.2	0.3	19	19.6	24	0.3	0.015	14	0.0082	MONTON
	61803	17	26	5	2.03	1.27	56 000	34 000	19.8	23.3	–	0.3	19	–	24	0.3	0.015	14	0.0075	MONTON
	61804-2RS1	20	32	7	4.03	2.32	–	13 000	23.8	–	29.4	0.6	22	23.6	30	0.3	0.015	15	0.018	MONTON
Previous12 3 4 5 6 7 Next

>>

<<

Select	Inquiry	Designation




















Previous12 3 4 5 6 7 Next
