Stainless Steel Type Metric Type thin section ball bearing -Stainless Steel Type Metric Type thin section ball bearing-Products-Luoyang Monton Bearing Science &Technology Co.,ltd.

Select	Download	Inquiry	Bearing Number	Dimensions in Inches	Capacities（lbs)	Wight（lbs）
Bore	Outside Dia.	L1	L2	L3	Radial	axial
Dynamic	Static	Dynamic	Static
			SAA10AG0	1.000	1.375	1.14	1.235	1.274	340	194	970	450	0.025
			SAA15AG0	1.500	1.875	1.64	1.735	1.774	480	238	1.380	560	0.038
			SAA17AG0	1.750	2.125	1.89	1.985	2.024	530	251	1.520	600	0.045
			SA020AR0	2.000	2.5	2.186	2.314	2.369	790	405	2.280	960	0.1
			SA025AR0	2.500	3	2.686	2.814	2.869	960	459	2.780	1.100	0.12
			SA030AR0	3.000	3.5	3.186	3.314	3.367	1.140	507	3.290	1.230	0.14
			SA035AR0	3.500	4	3.686	3.814	3.867	1.310	552	3.790	1.350	0.17
			SA040AR0	4.000	4.5	4.186	4.314	4.367	1.490	595	4.300	1.470	0.19
			SB020AR0	2.000	2.625	2.231	2.393	2.464	1.090	601	3.150	1.380	0.15
			SB025AR0	2.500	3.125	2.731	2.893	2.964	1.340	675	3.860	1.590	0.19
			SB030AR0	3.000	3.625	3.231	3.393	3.462	1.550	734	4.470	1.750	0.22
			SB035AR0	3.500	4.125	3.731	3.893	3.962	1.790	801	5.180	1.930	0.27
			SB040AR0	4.000	4.625	4.231	4.393	4.46	2.040	865	5.890	2.100	0.3
