Open Type Metric Type thin section ball bearing-Open Type Metric Type thin section ball bearing-Products-Luoyang Monton Bearing Science &Technology Co.,ltd.

Select	Download	Inquiry	Bearing Number	Dimensions in Inches	Capacities（lbs)	Wight（lbs）
Bore	Outside Dia.	L1	L2	L3	Radial	axial
Dynamic	Static	Dynamic	Static
			KAA10AG0	1.000	1.375	1.140	1.235	1.274	340	194	970	450	0.025
			KAA15AG0	1.500	1.875	1.640	1.735	1.774	480	238	1.380	560	0.038
			KAA17AG0	1.750	2.125	1.890	1.985	2.024	530	251	1.520	600	0.045
			KA020AR0	2.000	2.500	2.186	2.314	2.369	790	405	2.280	960	0.10
			KA025AR0	2.500	3.000	2.686	2.814	2.869	960	459	2.780	1.100	0.12
			KA030AR0	3.000	3.500	3.186	3.314	3.367	1.140	507	3.290	1.230	0.14
			KA035AR0	3.500	4.000	3.686	3.814	3.867	1.310	552	3.790	1.350	0.17
			KA040AR0	4.000	4.500	4.186	4.314	4.367	1.490	595	4.300	1.470	0.19
			KA042AR0	4.250	4.750	4.436	4.564	4.615	1.580	616	4.550	1.530	0.20
			KA045AR0	4.500	5.000	4.686	4.814	4.865	1.660	637	4.810	1.580	0.21
			KA047AR0	4.750	5.250	4.936	5.064	5.115	1.750	657	5.060	1.640	0.22
			KA050AR0	5.000	5.500	5.186	5.314	5.365	1.840	676	5.310	1.690	0.23
			KA055AR0	5.500	6.000	5.686	5.814	5.863	2.020	715	5.820	1.800	0.25
			KA060AR0	6.000	6.500	6.186	6.314	6.363	2.190	752	6.320	1.900	0.28
			KA065AR0	6.500	7.000	6.686	6.814	6.861	2.370	788	6.830	2.000	0.30
			KA070AR0	7.000	7.500	7.186	7.314	7.361	2.540	823	7.340	2.100	0.32
			KA075AR0	7.500	8.000	7.686	7.814	7.861	2.720	857	7.840	2.190	0.34
			KA080AR0	8.000	8.500	8.186	8.314	8.359	2.890	890	8.350	2.280	0.36
			KA090AR0	9.000	9.500	9.186	9.314	9.357	3.240	954	9.360	2.470	0.41
			KA100AR0	10.000	10.500	10.186	10.314	10.355	3.590	1.014	10.370	2.640	0.45
Previous12 3 4 5 6 7 Next
